QGF Mineral Water Bottle Filling Machine 5 Gallon Bottle Filling Machine

Name: QGF Mineral Water Bottle Filling Machine 5 Gallon Bottle Filling Machine
Brand: Aquatrin
Price: 2000 USD

Quality QGF Mineral Water Bottle Filling Machine 5 Gallon Bottle Filling Machine for sale

Brand Name : Aquatrin

Model Number : QGF

Certification : ISO CE

Place of Origin : China

MOQ : 1unit

Price : USD2000-60000 1Set

Payment Terms : T/T

Supply Ability : 10units per month

Delivery Time : 45days

Packaging Details : wooden package

Filling range : 3-5 Gallon

Usage : Beverage Filling Packaging

Processing Types : Automatic Bottle Filling Sealing Machine

Material : Stainless Steel 304/316

Filling Accuracy : 99%

Product name : Promotional Top Quality 5 Gallon Bottling Water Filling Machine

Contact Now

Main Feature

(1) QGF series automatic production line is specialized for production of 3-5 Gallon barrel.

(2) The machine consists of washing, filling and sealing in one.

 (3) The bottle washer adopts multi-channel washing liquid injection and disinfectant injection for the purpose of washing sterilization.The disinfectant is recyclable.

 (4) The sealing machine can start sealing automatically and the bottle conveying port is equipped with a sanitation device to ensure the sanitation of cap.

 (5) Washing, disinfection, filling, gland, counting and discharging is automatic.

 (6) The major electrical apparatus are all products of well-known brands, such as SIEMENS, MITSUBISHI, Schneider and OMRON.

 (7) This production line is an ideal choice for mineral water, distilled water and purified water with impact structure, small occupation of land and high automation.

QGF Mineral Water Bottle Filling Machine 5 Gallon Bottle Filling Machine

Containers and Specifications
Project Name: Full Automatic Complete 60-1200BPH 3-5 Gallon Barrel Filling Production Line			Mineral Water Pure Water
Material	Shape	Filling Volume	Filling Type
PC / PET	Round / Square	3 - 5 Gallon	Gravity filling Normal temperature
Adjustable Specifications of Bottle Type	Size of Barrel : ф276×490mm
	Customers need to buy exchange component for the different bottles. If using square bottles, then bottle separating system will be added.
Container Label	Sticker Label / Shrink Wrap Label / Printer Label
User Ambient Conditions	Temperature: 10~40℃ Humidity: No dew
User Electrical Supply Specification	Voltage: 380V±5% 3 Phase Frequency: 50HZ±1%

Washing Part

High pressure water with inside rinsing head to make sure fully cleaning with no dead angle.2.Up to 14 rinsing stations which can meet various hygiene standards and rinsing process.

Independent cycle recovery system to prevent mixing of cleaning fluids.

Filling Part

(1) Uploading and dropping barrels changed from 45 degree to translatory which is more stable.

 (2) Nozzle can insert into 10-15cm of the barrel in order to rinse little impurities down. Rinsing pump is separately controlled by different magnetic valves. Pump only work when there is barrel on that. It can avoid the mixture of different cleaning fluid.

Capping Parts

(1) Liquid level difference is controlled in 1cm.

 (2) Machine is equipped with Cap Sterilization system, which is 1.2m. The system make products more clean and safe by using sterilization and finished water.

 (3) Customers can choose to equip ABB/SEW motor, GRUNDFOS water pump, FESTO pneumatic component.

Product Tags:

QGF Water Bottle Filling Machine

380V Water Bottle Filling Machine

ISO 5 Gallon Bottle Filling Machine

QGF Mineral Water Bottle Filling Machine 5 Gallon Bottle Filling Machine Images
